TVS Apache RTR 200 4V
₹1.48 lakh – ₹1.5 lakh
- Brand
- TVS
- Type
- Bike
- Fuel
- Petrol
- Engine
- 197.75 cc
- Mileage
- 37 km/l
- Launched
- 20 Jan 2016
TVS Apache RTR 200 4V variants
TVS Apache RTR 200 4V Dual Channel ABS specifications
| Mileage | 37 km/l |
|---|---|
| Front brake | Disc |
| Rear brake | Disc |
| Fuel capacity | 12 L |
| Body type | Sports Naked Bikes, Sports Bikes |
| Overall mileage | 37 km/l |
|---|
| Engine type | Si, 4 Stroke, Oil Cooled, Fi |
|---|---|
| Displacement | 197.75 cc |
| Max torque | 17.25 Nm @ 7250 rpm |
| Number of cylinders | 1 |
| Cooling system | Air Cooled & Liquid Cooled |
| Valve per cylinder | 4 |
| Starting | Self Start Only |
| Fuel supply | Fuel Injection |
| Clutch | Wet Multi Plate Slipper Clutch With 5 Plate, Adjustable with 3 step position |
| Gear box | 5 Speed |
| Emission type | bs6-2.0 |
| Compression ratio | 10.0:1 |
| Ignition | Mapped ignition system |
| ABS | Dual Channel |
|---|---|
| Speedometer | Digital |
| Tripmeter | Digital |
| LED tail light | Yes |
| Odometer | Digital |
| Fuel gauge | Digital |
| Instrument console | Digital |
| Seat type | Split |
| Body graphics | Yes |
| Clock | Yes |
| Passenger footrest | Yes |
| Additional features of variant | (Maximum Speed - Urban/Rain Mode - 105 kmph), (Maximum Torque Urban/Rain Mode - 16.51 Nm @ 5750 rpm), (Maximum Power Urban/Rain Mode - 17.3 PS @ 7800 rpm), Oil cooled with ram air Assist, TVS SmartXonnect, Glide Through Technology, Muffler - Twin pipe and |
| Distance to empty indicator | Yes |
| Pass switch | Yes |
|---|---|
| Engine kill switch | Yes |
| Display | TFT |
| Riding modes | Rain,Sports,Urban |
| Traction control | Yes |
| Additional features | (Maximum Speed - Urban/Rain Mode - 105 kmph), (Maximum Torque Urban/Rain Mode - 16.51 Nm @ 5750 rpm), (Maximum Power Urban/Rain Mode - 17.3 PS @ 7800 rpm), Oil cooled with ram air Assist, TVS SmartXonnect, Glide Through Technology, Muffler - Twin pipe and |
| Width | 820 mm |
|---|---|
| Length | 2020 mm |
| Height | 1050 mm |
| Fuel capacity | 12 L |
| Ground clearance | 180 mm |
| Wheelbase | 1353 mm |
| Kerb weight | 151 kg |
| Fuel reserve | 2.5 L |
| Saddle height | 800 |
| Headlight | LED |
|---|---|
| Tail light | LED |
| Turn signal lamp | LED |
| LED tail lights | Yes |
| Low fuel indicator | Yes |
| Pilot lamps | Yes |
| Distance to empty indicator | Yes |
| Dr ls | Yes |
| Front brake diameter | 270 mm |
|---|---|
| Rear brake diameter | 240 mm |
| Radial tyre | Yes |
| Front suspension | Upside down suspension with 37D |
| Rear suspension | Mono Shock |
| Peak power | 20.82 PS @ 9000 rpm |
|---|---|
| Drive type | Chain Drive |
| Transmission | Manual |
| Battery capacity | 12V / 6AH |
| Suspension front | Upside down suspension with 37D |
|---|---|
| Suspension rear | Mono Tube - Mono Shock |
| Brakes front | Disc |
| Brakes rear | Disc |
| Tyre size | Front :-90/90-17 Rear :-130/70-17 |
| Wheel size | Front :-431.8 mm,Rear :-431.8 mm |
| Wheel type | Alloy |
| Tubeless tyre | Tubeless |
| Charging at home | No |
|---|---|
| Charging at charging station | No |
